L2 Series
Sprecher + Schuh’s comprehensive line of L2 rotary cam switches are available for all control and load applications up to 25 amps. The line is modular and has many convenience and safety features. A well-thought-out ordering system provides many standard and nonstandard configurations that are many times available off the shelf.
Any switch configuration…
Two frame sizes provide control and load switching up to 25 amps, with as few as two, and as many as 16 contacts. Both frame sizes are available in panel mount and base mount for total flexibility. A wide range of switching configurations are offered from stock.
Shaft extensions and door interlocks snap-on quickly without tools, saving time during assembly. Captive terminals are shipped open and are totally accessible regardless of whether the switch is base mounted or panel mounted. Screwdriver guides and clear terminal markings reduce wiring mistakes and speed installation. In addition, most switch handle assemblies are available with either screw fixing or the central nut mounting system for total flexibility.
R-Line
Sprecher + Schuh’s rugged R-Line rotary cam switches are available for most control and load applications up to 40 amps. As with our smaller L2 Series switches, a well-thought-out ordering system provides many standard and nonstandard configurations that are often available “off the shelf.”
A comprehensive line…
The R40 is available in panel mount and base mount for total flexibility. Many popular switching configurations are offered from stock.
The R-Line’s sturdy design incorporates a positive switching action with a clearly defined switch position. The R40 is designed with a solid steel shaft that provides instantaneous operation of double-break silver alloy contacts, while powerful springs assure complete contact closure. The contact assemblies themselves are brass plated and have generous copper content to help dissipate heat.
